Durata de livrare: 3-7zile
Cod Produs:
C304
Ai nevoie de ajutor?
0736579964
- Descriere
- Review-uri (0)
- Numar tuburi: 10
- Suprafata bruta (ISFH): 1.54 m²
- Suprafata de apertura/activa (ISFH): 0.94 m²
- Volum agent termic: 0.77 l
- Dimensiuni: 1920x800x100mm (Lxlxh)
- Masa neta: 36.00 kg
- Volum boiler recomandat: 100 l
- Presiune de test: 10 bar
- Presiune maxima de lucru: 6 bar
- Temperatura maxima apa: 100°C
- Temperatura maxima stagnare (agent termic fara circulatie): 210°C
- Tub exterior (Dexg): 58x2.0mm
- Tub interior (Dixg): 47x1.6mm
- Distanta intre tuburi: 75mm
- Debit agent termic recomandat: 50 - 150 l/m²h
- Inclinare min/max: 15/75°
- Dimensiuni tub vidat: Ø58x1800mm
- Grosime izolatie: 40mm
Informatii conformitate produs
- Suprafata bruta (ISFH): 1.54 m²
- Suprafata de apertura/activa (ISFH): 0.94 m²
- Volum agent termic: 0.77 l
- Dimensiuni: 1920x800x100mm (Lxlxh)
- Masa neta: 36.00 kg
- Volum boiler recomandat: 100 l
- Presiune de test: 10 bar
- Presiune maxima de lucru: 6 bar
- Temperatura maxima apa: 100°C
- Temperatura maxima stagnare (agent termic fara circulatie): 210°C
- Tub exterior (Dexg): 58x2.0mm
- Tub interior (Dixg): 47x1.6mm
- Distanta intre tuburi: 75mm
- Debit agent termic recomandat: 50 - 150 l/m²h
- Inclinare min/max: 15/75°
- Dimensiuni tub vidat: Ø58x1800mm
- Grosime izolatie: 40mm
